MMP Series | MMP 450/520/630VDC

規格說明

Capacitor Range : 0.1μF ~2.2μF

Rated Voltages : 450/520/630VDC

Tolerance : J(±5%),K(±10%)

Temperature range :-40℃ to +110℃. (+85℃ to +110℃ : Decreasing factor 1.25% per ℃ for Ur)

Dissipation Factor(DF) :

KHz	C＜1.0μF	1.0μF≦C  ≦2.2μF
1	≦0.1 %	≦0.15 %
100	≦1.5 %	≦2.5 %

Insulation Resistance : ≥15,000 Mohm (C≤0.33uf)  ≥5,000 Mohm*uF/C (C>0.33uf)

Withstand Voltage : Terminal to Terminal: (at 20°C±5°C)
                                   1.75 × VR applied for 2sec. (cut off current 10mA)

額定電壓脈衝斜率 dV/dt (V/μs) Rated Voltage Pulse Slope dV/dt (V/μs)		10mm	15mm	22.5mm
	450VDC	100	80	60
	520VDC	160	120	70
	630VDC	200	150	100
